3D Fiber Laser Marking Machine-Portable Type

WISELY 3D serial fiber laser marking machine adopt imported core components, with high-speed, high precision 3D galvo, and with our 3D specified software and control system, it can engrave on any curved workpieces in a fine process, there is no off-focus problem. It can also adjust focus length any time for deep engraving, which make process efficiency and marking quality much better than traditional 2D fiber laser marking machine. we make real 3D marking function come true, leading a new era of laser processing.
Contact information

0086-150-1350-9330

  • Technical Parameters


Advantages

1) 3D marking:  can do smooth and uniform marking effect on slope, cylinder, cone, ball and so on.

2) Terrific big central angle marking , the max. central angle can reach 117 degree on cylinder.

3) Perfectly present target graphics on work pieces, avoid deforming such as elongation and slope.

4) Long lifespan of fiber laser source: 100 000 hours.

5) No Consumables: One marker can work for more than 10 years without any consumables.

6) The fiber laser beam comes out from the fiber device directly, no need to adjust the laser optical path.

7) High-stability controller, USB interface, swift and stable transmission, route optimization, intelligent
    calculation, easy software.

Technical Parameters

TypeMY-M30F-III (3D)
Laser Power30W
Optional Laser Power30W/50W /100w
Laser Wavelength1064nm
Marking Area100mm*100mm
Optional Marking Area     70*70mm /150*150mm /175*175mm /200*200mm          300*300mm /400*400mm /500*500mm /600*600mm
Marking Speed10000mm/s
Minimum Line Width0.03mm
Repeated Precision±0.006mm
Fiber Laser SourceJPT LP Laser Source From China
Life-span of Fiber Laser Source100 000 hours
Beam QualityM2 <1.3
Focus Spot Diameter<0.02mm
Output Power of Laser10%~100% to be adjusted continuously
Output Frequency of Laser1~600KHz to be adjusted continuously
Power Stability (8h)<±1%rms
System Operation EnvironmentWindows XP / 7 / 8 / 10 - 32 / 64bits
Cooling ModeAir cooling
Temperature of Operation Environment0℃~ 40℃
Humidity of Operation Environment5% ~ 75%
Power Input220V/50HZ/1-Ph or 110V/60HZ/1-ph
Power Comsuption<450W
Communication InterfaceUSB
Dimension (L*W*H)750*630*650mm
Package Size830*700*810mm
Net Weight120Kg
Gross Weight165Kg


Optional Devices

Optional Devices-Fiber-水印.png



































payment

100% or 40% prepaird before production, balance payment before shipment. (Negotiable)

Bank Wire, Paypal, Western Union, Credit Card, Alibaba.

Shipment

Machine will be sent out 5-10 working days after receiving the payment.

By Express: 6-10 days.

By Sea: 30-45 days. (Recommended)


Packaging

International standard plywooden case.


Warranty

Whole machine has a warranty period of 24 months since the production date.


Training

1~3 working days training free of charge in factory or online training via TeamViewer, Skype, WeChat, FB.
